Suited for: 25-35T Excavator
Weight: 2145kgs
Operating pressure: 160-180 Bar
Req. flow: 150-210 lt/min
Tool diameter: 150mm
Impact energy: 9850 Joules

Pins: 90mm | Pin Centers: 510mm | Between the Ears: 410mm
Pins: 100mm | Pin Centers: 585mm | Between the Ears: 440mm
Pins: 100mm | Pin Centers: 515mm | Between the Ears: 440mm
Pins: 110mm | Pin Centers: 600mm | Between the Ears: 460mm

Includes: Spare Chisel, Hydraulic Hoses and Hydraulic Fittings

Warranty: 24-months (excludes hydraulic hoses and chisel)
